Min: 1 EAC
|Type of electric connection||Screw connection|
|Function delay-on energization||No|
|Function delay on de-energization||No|
|Function floating contact on energization||No|
|Function floating contact on de-energization||No|
|Function pulse shaping||No|
|Function flashing, starting with pause, fixed time||No|
|Function flashing, starting with pulse, fixed time||No|
|Clock function, starting with pause, variable||Yes|
|Clock function, starting with pulse, variable||Yes|
|With plug-in socket||No|
|Remote operation possible||No|
|Suitable for remote control||No|
|Pluggable on auxiliary contact block||No|
|Rated control supply voltage Us at AC 50HZ||24 V|
|Rated control supply voltage Us at AC 60HZ||24 V|
|Rated control supply voltage Us at DC||24 V|
|Voltage type for actuating||AC/DC|
|Number of outputs, undelayed, normally closed contact||0|
|Number of outputs, undelayed, normally open contact||0|
|Number of outputs, undelayed, change-over contact||0|
|Number of outputs, delayed, normally closed contact||1|
|Number of outputs, delayed, normally open contact||1|
|Number of outputs, delayed, change-over contact||1|
|Outputs, reversible delayed/undelayed||No|
|With semiconductor output||No|
|Suitable for DIN rail (top hat rail) mounting||Yes|
|Suitable for front mounting||No|
