Motor protection circuit-breaker |
|
Overload release current setting |
6 A
|
---|---|
Adjustment range undelayed short-circuit release |
138 A
|
With thermal overload protection |
Yes
|
Phase failure sensitive |
Yes
|
Switch off technique |
Thermomagnetic
|
Rated operating voltage |
230 V
|
Rated permanent current Iu |
10 A
|
Rated operation power at AC-3, 230 V |
2.2 kW
|
Rated operation power at AC-3, 400 V |
4 kW
|
Type of electrical connection of main circuit |
Screw connection
|
Type of control element |
Push button
|
Device construction |
Complete device in housing
|
With integrated auxiliary switch |
No
|
---|---|
With integrated under voltage release |
No
|
Number of poles |
3
|
Rated short-circuit breaking capacity lcu at 400 V, AC |
100 kA
|
Degree of protection (IP) |
IP20
|
Height |
89 mm
|
Width |
45 mm
|
Depth |
78.2 mm
|
Thermal protection |
Yes
|
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
100
|
Number of poles (total) |
3
|
Method of operation |
Rocker lever
|
