MULTIFUNC LEV CONTRL DISCRT 24-240VAC/DC
Rexel Part:
SCDRM35LV14MW
Mfr Number:
RM35LV14MW
Barcode:
3389119405249
Please LogIn
To view pricing, availability and special offers, click the button below and login.
Contact your local branch for availability.
Supplier Packages :
Package options may not always be available
Package Options
Number of items
1 Pack
48 EAC
EAC
Min: 1 EAC
Technical Documents
Technical Documents
Product Details
Product Details
This Zelio RM35 - LV relay allows monitoring of LEVEL control in 3 - phase networks This modular multi function 3 - phase liquid LEVEL control relay is ideal for monitoring of electrical values in industrial and building cont
"This Harmony RM35-LV relay allows monitoring of level control in 3-phase networks." "This modular multi function 3-phase liquid level control relay is ideal for monitoring of electrical values in industrial and building control panels." "It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water." "It has one of market medium form-factors with 35mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 3-pole DIN device." "It also offers a sealable cover, simple and precise settings with screw trimmers." "It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting." "multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC." 0 0 0 0 0 0 0 0 0
"This Harmony RM35-LV relay allows monitoring of level control in 3-phase networks." "This modular multi function 3-phase liquid level control relay is ideal for monitoring of electrical values in industrial and building control panels." "It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water." "It has one of market medium form-factors with 35mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 3-pole DIN device." "It also offers a sealable cover, simple and precise settings with screw trimmers." "It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting." "multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC." 0 0 0 0 0 0 0 0 0
Technical Specifications
Technical Specifications
(Fill) level monitoring relay | |
| Depth | 72 mm |
|---|---|
| Type of electric connection | Screw connection |
| Response value sensitivity adjustable | Yes |
| With detachable clamps | No |
| Width | 35 mm |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as change-over contact | 1 |
| Min. adjustable off-delay time | 0.1 s |
| Physical measurement principle | Float |
|---|---|
| Min. adjustable operate delay time | 0 s |
| Max. permitted operate delay time | 0.5 s |
| Max. permitted off-delay time | 5 s |
| Cascadable | No |
| Height | 90 mm |
| Number of contacts as normally open contact | 0 |
| Number of inputs for electrodes | 3 |
