Molded Case Circuit Breaker 600V 125A
Rexel Part:
SC2HGL36125
Mfr Number:
HGL36125
Barcode:
785901598831
Please LogIn
To view pricing, availability and special offers, click the button below and login.
Contact your local branch for availability.
EAC
Min: 1 EAC
Technical Documents
Technical Documents
Product Details
Product Details
The PowerPact H-, J-, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H- and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. The new generation PowerPact with Micrologic circuit breakers set the standard with direct access to energy management. Integrated metering enhances their protective functions. For the first time, Schneider Electric™ users can monitor energy from 15 to 3000 A, offering new performance in a remarkably compact device. This PowerPact H, circuit breaker has a rated current of 125A and is a 3P breaker. This breaker has a breaking capacity of 18kA@600VACand has an thermal-magnetic trip technology. This breaker complies to UL, CE, IEC & CSA standards. Thermal current for this breaker has a magnetic tripping current of 1700A. Dimensions for this breaker are 6.4 in (H),4.12 in (W),4.36 in (D) and has an ambient temperature of 40 °C. This product comes with an 18 months warranty.
Technical Specifications
Technical Specifications
Does this product not have all the specifications you are looking for?
Please don't hesitate to conduct a search for other products with similar technical specifications.
To find similar products, please select the desired specifications from the white boxes below.
To help with your selection, try selecting the Select All button below then deselect any unwanted specification.
Please select at least 1 attribute to search.
Power circuit breaker (MCCB) |
|
| Motor drive integrated |
No
|
|---|---|
| Type of electrical connection of main circuit |
Other
|
| Complete device with protection unit |
Yes
|
| Rated permanent current Iu |
125 A
|
| Suitable for DIN rail (top hat rail) mounting |
No
|
| DIN rail (top hat rail) mounting optional |
No
|
| Integrated earth fault protection |
No
|
| Number of poles |
3
|
| Device construction |
Built-in device fixed built-in technique
|
|---|---|
| Type of control element |
Toggle
|
| Position of connection for main current circuit |
Front side
|
| With switched-off indicator |
No
|
| Degree of protection (IP) |
front cover: IP40 conforming to IEC 60529
|
| Adjustment range undelayed short-circuit release |
1,700-1,700 A
|
| Rated voltage |
600-600 V
|
