Connector Straight M12 Male 5 Pin
Rexel Part:
TELXZCC12MDM50B
Mfr Number:
XZCC12MDM50B
Barcode:
3389110806250
Please LogIn
To view pricing, availability and special offers, click the button below and login.
Contact your local branch for availability.
EAC
Min: 1 EAC
Technical Documents
Technical Documents
Product Details
Product Details
This connector has a straight male 5 - pin M12 connector and a screw terminal with metal clamping rings It is designed for critical installations thanks to the high robustness metallic ring M12 connector
This connector has a straight male 5-pin M12 connector and a screw terminal with metal clamping rings. It is designed for critical installations thanks to the high robustness metallic ring M12 connector.
This connector has a straight male 5-pin M12 connector and a screw terminal with metal clamping rings. It is designed for critical installations thanks to the high robustness metallic ring M12 connector.
Technical Specifications
Technical Specifications
Circular connector for field assembly (industrial connector) | |
| Material thread ring | Other |
|---|---|
| Connectable conductor cross section multi-wired | 0 mm² |
| With status indication | No |
| For cable outer diameter | 7 mm |
| Thread size M | 20 |
| Coating housing | None |
| Contact type | Pin |
| Connectable conductor cross section solid-core | 0 mm² |
| Rated current In | 3 A |
| Inflammability class of insulation material according to with UL94 | Other |
| Ambient temperature | -40 °C |
| Material of contact surface | Other |
| Degree of protection (IP), mounted | IP67 |
|---|---|
| Connectable conductor cross section fine-strand without cable end sleeve | 0 mm² |
| Type of electric connection | Screw connection |
| Type of locking | None |
| Connectable conductor cross section fine-strand with cable end sleeve | 0 mm² |
| Housing material | Other |
| Screened | No |
| Rated voltage | 30 V |
| With protective conductor | No |
| Number of data contacts | 5 |
| Diameter connector | 12 mm |
| Type of housing | Straight |
